The ballroom plot, without opening CAD
Stage decks, LED walls, FOH, truss, distro, and cable paths — drawn to scale in real feet and inches, checked in 3D for sightlines, and shared as a link the venue and client can approve without buying a seat.
The library
Gear that's actually in the object library
Stage decks that add up
4′×8′ and 4′×4′ decks, risers with real trim heights, stairs and skirting. Place three decks and the plan says 24′ × 8′, because it is.
LED walls & projection
Vertical surfaces carry Width × Height, not a flattened footprint — so a 30′ × 10′ wall reads correctly in plan and in 3D.
Truss, towers & rigging
Truss runs and towers with trim height, plus the ground-supported goalposts you actually build in a ballroom with no rigging points.
Power, distro & cable paths
400A and 200A distro, feeder bundles, dog houses, and cable ramps — so the plan shows how the room gets fed, not just where the tables go.
FOH, cameras & control
FOH console positions, camera risers, and confidence monitors — the positions that get argued about at 6am on load-in day.
Client approval without seats
Send the plot as a link. The venue, the planner, and the client comment and approve — none of them buys a license to do it.
Every object carries real dimensions and a real height. Nothing here is a decorative icon — the item tally that comes off a plan is the load list you hand your warehouse.
Sightlines
Check the screen before the truck rolls
One click from the plan. Stage height, screen size, and the back-of-room view — the questions a client asks that a 2D PDF can't answer.
FAQ
Questions from the shop
- Is this a CAD replacement?
- No, and it isn't trying to be. Keep Vectorworks or AutoCAD for arena builds and rigging plots that need real structural work. EventDiagram is for the 80% of jobs that are a ballroom, a stage, two screens, and rounds — where CAD is overkill and the current alternative is marking up the venue's PDF.
- Can I keep private technical layouts separate from the venue's plan?
- Yes. The venue owns its authoritative room plan; you keep your own diagrams, object catalogs, and layers. Layers toggle independently — hand the caterer a clean plan, keep cable paths and distro on a layer only your crew sees.
- Do vertical objects carry real height?
- Every object has a physical height, because the 3D walkthrough renders from the same scene data as the 2D plan. Screens, LED walls, and drape expose Width × Height; their plan-view depth is the real footprint. There is no separate 3D model to maintain.
- What does it cost for a small production company?
- Planner Pro at $39/month covers an individual producer with unlimited events and the full production library. Planner Team at $99/month adds five editors, shared templates, and a team brand kit. Monthly billing, cancel anytime — no annual commitment.
